| UJ19 SPECIFICATIONS | |||
| HOLE RANGE | mm | 45 - 89 | |
| ROD LENGTH | mm | 3050 | |
| DRILLING DEPTH | m | 15 | |
| HYDRAULIC DRIFTER | IMPACT POWER | Kw | 15 |
| ROTATION SPEED | Rpm | 0 - 300 | |
| ROTATION SYSTEM | Independent Rotation | ||
| SHANK | R32 / T38 | ||
| FEED BEAM LENGTH | 4890 | ||
| WATER PUMP | WORKING PRESSURE | Bar | 12 |
| FREE AIR DELIVERY | m3/h | 4 | |
| AIR COMPRESSOR | WORKING PRESSURE | Bar | 8 |
| FREE AIR DELIVERY | m3/h | 0.3 | |
| DIESEL ENGINE | Brand | Cummins | |
| Kw | 75 |
||
| ELECTRIC MOTOR | Kw | 45 | |
| CHASSIS | TRAMMING SPEED max | Km/h | 3,6 high - 2,3 low |
| CLIMBING ABILITY | () ° | 20 | |
| TURNING RADIUS (I/O) | mm | 2.535 / 4.800 | |
| WORKING FACE (WxH) | mm | 5.968 x 5.145 | |
| WORKING AREA | m2 | 28 | |
| WEIGHT | Kg | 11000 | |
| SHIPPING DIMENSIONS (LXWXH) | mm | 12.160 x 1.450 x (1400 Retr- 2.035 Ext) | |
